[C++] Make a CTF Gameplay for your MP Mod

NOTE: This code will need modifying to suit your team system,ect so don't take this as a complete C&P (which it basically is).

#1 - Creating Flag entity
In a new header file (ctf_gameplay.h), put this :

Code:

// Status of the flag
#define FLAG_STOLEN 1
#define FLAG_CAPTURE    2
#define FLAG_DROPPED    3

// Our flag class which holds all our functions and variables we're going to use

class CObjectFlag : public CBaseEntity
{
public:
    void Spawn( );
    void Precache( );
    void Touch(CBaseEntity *);
    bool m_fIsInPlay;
};

// The Flag entity that is dropped by a player when killed/disconnected/whatnot
class CDroppedFlag : public CBaseEntity
{
public:
    void Spawn( );
    void Precache( );
    void Touch(CBaseEntity *);
};

In player.h put the code below in class CBasePlayer : public CBaseMonster in public :

Code:

bool m_fHasObject;

In a new .cpp file (ctf_gameplay.cpp), put the following :

Code:

// includes needed for everything to compile
#include "extdll.h"
#include "decals.h"
#include "util.h"
#include "cbase.h"
#include "monsters.h"
#include "weapons.h"
#include "nodes.h"
#include "player.h"
#include "soundent.h"
#include "shake.h"
#include "gamerules.h"
#include "ctf_object.h"
#include "teamplay_gamerules.h"

LINK_ENTITY_TO_CLASS( object_flag, CObjectFlag );

void CObjectFlag :: Spawn( )
{
    // Calls the precache function to precache any models, sounds,ect you need
    //before it spawns
    Precache( );
    // Setup what model we want to use for the flag, change this to
    // whatever you want. Just remember precache it.
    SET_MODEL( ENT(pev), "models/flag.mdl" );

    UTIL_SetOrigin( pev, pev->origin + Vector(0,0,10) );
    UTIL_SetSize( pev, Vector(-16,-16,0), Vector(16,16,16) );

    // This is so it falls to the brush below it
    pev->movetype = MOVETYPE_TOSS;

    // This allows you to trigger it by walking through it
    pev->solid = SOLID_TRIGGER;

    // This just sets our Touch to Touch, which is down a little further
    SetTouch(Touch);

    // This just makes a GlowShell around the model, you can
    // change the colour of the shell by changing the RGB values,
    // which are the XYZ values in this case. So at the moment we have
    // a nice bright red colour. Feel free to change this to your needs.
    pev->renderfx = kRenderFxGlowShell;
    pev->rendercolor.x = 255;
    pev->rendercolor.y = 0;
    pev->rendercolor.z = 0;
    pev->renderamt = 10; // 10 units off the sides of the model

    // This just sets our IsInPlay bool to false, because its only just spawned and
    // no one has picked it up yet.
    m_fIsInPlay = false;
}

// This is the Precache function which is called from the Spawn function.

void CObjectFlag :: Precache( )
{
    // Precache's the model
    PRECACHE_MODEL( "models/flag.mdl" );
}

// This is the Touch function which was set above, in the Spawn function,
// its basically the stuff that runs when the flag has been touched by a player

void CObjectFlag :: Touch(CBaseEntity *pOther)
{
    // If its in play, do nothing
    if(m_fIsInPlay)
        return;

    // Determine if the object that touches it, is a player
    // and check if the player is alive.
    if(!pOther)
         return;
    if(!pOther->IsPlayer())
         return;
    if(!pOther->IsAlive())
         return;

    CBasePlayer *pPlayer = (CBasePlayer *)pOther;

    // Print to the HUD who has taken the flag
    UTIL_ClientPrintAll( HUD_PRINTCENTER, UTIL_VarArgs( "%s has the Flag!\n", STRING( pPlayer->pev->netname )));

    pPlayer->m_fHasObject = true;

    // Set the client attachment using an event
    PLAYBACK_EVENT_FULL(0, pPlayer->edict(), g_usObject, 0, (float *)&g_vecZero, (float *)&g_vecZero, 0, 0, FLAG_STOLEN, 0, 0, 0);

    m_fIsInPlay = true;

    // Give the illusion of the player taking the model by not drawing it
    pev->effects = EF_NODRAW;

    // Now don't let it accept any more touch's
    SetTouch(NULL);
}

Code:

// This is the Flag that is dropped by a player when killed,disconnected,ect.
// Its basically the same as CObjectFlag, with a few changes.

LINK_ENTITY_TO_CLASS( dropped_flag, CDroppedFlag );

void CDroppedFlag :: Spawn( )
{
    // Calls the precache function to precache any models or sounds,ect
    // you need before it spawns.
    Precache( );

    // Setup what model we want to use for the flag, change this to
    // whatever you want. Just remember precache it.
    SET_MODEL( ENT(pev), "models/flag.mdl" );

    UTIL_SetOrigin( pev, pev->origin );
    UTIL_SetSize( pev, Vector(-16,-16,0), Vector(16,16,16) );

    // This is so it falls to the brush below it
    pev->movetype = MOVETYPE_TOSS;

    // This allows you to trigger it by walking through it
    pev->solid = SOLID_TRIGGER;

    // This just sets our Touch to Touch, which is down a little further
    SetTouch(Touch);

    // This just makes a GlowShell around the model, you can
    // change the colour of the shell by changing the RGB values,
    // which are the XYZ values in this case. So at the moment we have
    // a nice bright red colour. Feel free to change this to your needs.
    pev->effects = EF_BRIGHTFIELD;
    pev->renderfx = kRenderFxGlowShell;
    pev->rendercolor.x = 255;
    pev->rendercolor.y = 0;
    pev->rendercolor.z = 0;
    pev->renderamt = 10; // 10 units off the sides of the model
    pev->avelocity.z = 25;
}

// This is the Precache function which is called from the Spawn function.

void CDroppedFlag :: Precache( )
{
    // Precache's the model
    PRECACHE_MODEL( "models/flag.mdl" );
}

// This is the Touch function which was set above, in the Spawn function,
// its basically the stuff that runs when the flag has been touched by a player.

void CDroppedFlag :: Touch(CBaseEntity *pOther)
{
    // Determine if the object that touches it, is a player
    // and check if the player is alive.
    if(!pOther)
         return;
    if(!pOther->IsPlayer())
         return;
    if(!pOther->IsAlive())
         return;

    CBasePlayer *pPlayer = (CBasePlayer *)pOther;

    // Print to the HUD who has taken the flag
    UTIL_ClientPrintAll( HUD_PRINTCENTER, UTIL_VarArgs( "%s has the Flag!\n", STRING( pPlayer->pev->netname )));

    // Set it to true because the player has the flag
    pPlayer->m_fHasObject = true;

    // Set the client attachment using an event
    PLAYBACK_EVENT_FULL(0, pPlayer->edict(), g_usObject, 0, (float *)&g_vecZero, (float *)&g_vecZero, 0, 0, FLAG_STOLEN, 0, 0, 0);

    // remove this item
    SetThink(SUB_Remove);

    // next think time to now!
    pev->nextthink = gpGlobals->time;
}

In teamplay_gamerules in void CHalfLifeTeamplay :: PlayerKilled, put the following :

Code:

    // If they have the flag, drop it.
    if( pVictim->m_fHasObject )
    {
         // Print to HUD who has dropped the flag
         UTIL_ClientPrintAll( HUD_PRINTNOTIFY, UTIL_VarArgs( "%s has dropped the Flag!\n", STRING( pPlayer->pev->netname )));

         // Creates the flag entity in the direction the player is facing
         CDroppedFlag *pFlag = (CDroppedFlag *)CBaseEntity::Create("dropped_flag", pVictim->pev->origin, pVictim->pev->angles);

         // Player no longer has flag so set the bool to false
    pVictim->m_fHasObject = false;

         // Update client with what has happened
         PLAYBACK_EVENT_FULL(0, pVictim->edict(), g_usObject, 0, (float *)&g_vecZero, (float *)&g_vecZero, 0, 0, FLAG_DROPPED, 0, 0, 0);
    }

multiplay_gamerules.cpp, CHalfLifeMultiplay :: ClientDisconnected( edict_t *pClient ) before this :

Code:

if ( pClient )
{
    CBasePlayer *pPlayer = (CBasePlayer *)CBaseEntity::Instance( pClient );

Put this :

Code:

    // If they have the flag, drop it
if( pPlayer->m_fHasObject )
{
    // Print to HUD who has dropped the flag
    UTIL_ClientPrintAll( HUD_PRINTNOTIFY, UTIL_VarArgs( "%s has dropped the Flag!\n", STRING( pPlayer->pev->netname )));

    // Creates the flag entity in the direction the player is facing
    CDroppedFlag *pFlag = (CDroppedFlag *)CBaseEntity::Create("dropped_flag", pPlayer->pev->origin, pPlayer->pev->angles);

    // Player no longer has flag so set the bool to false
    pPlayer->m_fHasObject = false;

    // Update client with what has happened
    PLAYBACK_EVENT_FULL(0, pPlayer->edict(), g_usObject, 0, (float *)&g_vecZero, (float *)&g_vecZero, 0, 0, FLAG_DROPPED, 0, 0, 0);

}

Now in weapons.cpp find, DLL_GLOBAL short g_sModelIndexBloodSpray; and put the following after it:

Code:

    DLL_GLOBAL unsigned short g_usObject; // object capture/taken event

Now find g_sModelIndexBloodSpray = PRECACHE_MODEL ("sprites/bloodspray.spr");
and put the following after it:

Code:

    g_usObject = PRECACHE_EVENT(1, "events/object.sc");

Now in weapons.h fine, extern DLL_GLOBAL short g_sModelIndexBloodSpray; and put the following after it:

Code:

    extern DLL_GLOBAL unsigned short g_usObject; // object capture/stolen event

#2 - Creating Capture Point Entity
Open "ctf_gameplay.h" and put at the bottom :

Code:

// Capture point for Team 1
class CCaptureTeam1 : public CBaseEntity
{
public:

       void Spawn( );
       void Precache( );
       void EXPORT Touch(CBaseEntity *);
       void EXPORT Think( );
       void KeyValue( KeyValueData* );
};


// Capture point for Team 2
class CCaptureTeam2 : public CBaseEntity
{
public:

       void Spawn( );
       void Precache( );
       void EXPORT Touch( CBaseEntity *);
       void EXPORT Think( );
       void KeyValue( KeyValueData* );
};

In player.h, put the following in class CBasePlayer : public CBaseMonster
in the publics under bool m_fHasObject;

Code:

    bool m_bInCapture;

In the bottom of ctf_gameplay.cpp, put this :

Code:

LINK_ENTITY_TO_CLASS( capture_team1, CCaptureTeam1 );

void CCaptureTeam1 :: Spawn( )
{

    // Calls the precache function to precache any models, sounds,ect
    // you need before it spawns
    Precache( );

    SET_MODEL( ENT(pev), STRING(pev->model) );

    UTIL_SetOrigin( pev, pev->origin );
    pev->movetype = MOVETYPE_FLY;

    // This allows you to trigger it by walking through it
    pev->solid = SOLID_TRIGGER;

    // This just sets our Touch to Touch and our Think to Think
    // which is down a little further.
    SetTouch(Touch);
    SetThink(Think);

    // Sets next think time
    pev->nextthink = gpGlobals->time + 0.1;

    // Make the entity invisible
    pev->rendermode = kRenderTransTexture;
    pev->renderamt = 0;

}

// This is the Precache function which is called from the Spawn function.

void CCaptureTeam1 :: Precache( )
{
    PRECACHE_MODEL( (char*)STRING(pev->model) );
}
void CCaptureTeam1 :: Think( )
{
    // loop through every player and check if they are in the area
    for(int i=0; i<gpGlobals->maxClients; i++)
    {
         CBasePlayer *pPlayer = (CBasePlayer *)UTIL_PlayerByIndex(i);
         if(pPlayer && pPlayer->m_iTeam == 1)
         {
    if((pPlayer->pev->origin.x >= pev->mins.x) && (pPlayer->pev->origin.x <= pev->maxs.x) &&
    (pPlayer->pev->origin.y >= pev->mins.y) && (pPlayer->pev->origin.y <= pev->maxs.y) &&
    (pPlayer->pev->origin.z >= pev->mins.z) && (pPlayer->pev->origin.z <= pev->maxs.z))
    pPlayer->m_bInCapture = true;
    else
    pPlayer->m_bInCapture = false;
          }
    }

    // Set next think time
    pev->nextthink = gpGlobals->time + 0.1;
}

// This is the Touch function which was set above, in the Spawn function,
// its basically the stuff that runs when the capture point has been touched by a player

void CCaptureTeam1 :: Touch( CBaseEntity* pOther )
{
    // Determine if the object that touches it, is a player
    // and check if the player is alive.
    if(!pOther)
        return;
    if(!pOther->IsPlayer())
        return;
    if(!pOther->IsAlive())
        return;

    CBasePlayer *pPlayer = (CBasePlayer *)pOther;

    if(pPlayer && pPlayer->m_iTeam == 1)
    {
        // Check to see if they have the object
        if( !pPlayer->m_fHasObject )
             return;
        else
        {
                // Print to HUD who has captured the flag
                UTIL_ClientPrintAll( HUD_PRINTCENTER, UTIL_VarArgs
                ( "%s has captured the Flag!\n", STRING( pPlayer->pev->netname )));

                 // Remove the flag
                 pPlayer->m_fHasObject = false;

                 PLAYBACK_EVENT_FULL(0, pPlayer->edict(), g_usObject, 0, (float *)&g_vecZero,
                 (float *)&g_vecZero, 0, 0, FLAG_CAPTURE, 0, 0, 0);


                 // Reset the flag
                 CObjectFlag *pFlag = (CObjectFlag *)UTIL_FindEntityByClassname(NULL, "object_flag");
                 if(pFlag)
                 {
                        pFlag->m_fIsInPlay = false;

                        // Do a funky effect on the flag when it gets reset
                        pFlag->pev->effects = EF_BRIGHTFIELD;
                 }
        }
    }
    else
        return; // wrong team
}

void CCaptureTeam1 :: KeyValue( KeyValueData* Data )
{
   // This will store the points but its not fully implemented. I'll leave it for you to do.
    if( FStrEq( Data->szKeyName, "points" ) )
    {
    int m_iPoints = atoi(Data->szValue);
    Data->fHandled = true;
    }

    CBaseEntity::KeyValue(Data); // call the parent function
}

Code:

LINK_ENTITY_TO_CLASS( capture_team2, CCaptureTeam2 );

void CCaptureTeam2 :: Spawn( )
{
    // Calls the precache function to precache any models, sounds,ect
    // you need before it spawns.
    Precache( );

    SET_MODEL( ENT(pev), STRING(pev->model) );

    UTIL_SetOrigin( pev, pev->origin );
    pev->movetype = MOVETYPE_FLY;

    // This allows you to trigger it by walking through it
    pev->solid = SOLID_TRIGGER;

    // This just sets our Touch to Touch and our Think to Think
    // which is down a little further.
    SetTouch(Touch);
    SetThink(Think);

    // Set next think time
    pev->nextthink = gpGlobals->time + 0.1;

    // Make the entity invisible
    pev->rendermode = kRenderTransTexture;
    pev->renderamt = 0;
}

void CCaptureTeam2 :: Precache( )
{
    PRECACHE_MODEL( (char*)STRING(pev->model) );
}
void CCaptureTeam2 :: Think( )
{
    // loop through every player and check if they are in the area
    for(int i=0; i<gpGlobals->maxClients; i++)
    {
         CBasePlayer *pPlayer = (CBasePlayer *)UTIL_PlayerByIndex(i);
         if(pPlayer && pPlayer->m_iTeam == 2)
         {
             if((pPlayer->pev->origin.x >= pev->mins.x) && (pPlayer->pev->origin.x <= pev->maxs.x) &&
             (pPlayer->pev->origin.y >= pev->mins.y) && (pPlayer->pev->origin.y <= pev->maxs.y) &&
             (pPlayer->pev->origin.z >= pev->mins.z) && (pPlayer->pev->origin.z <= pev->maxs.z))
             pPlayer->m_bInCapture = true;
             else
             pPlayer->m_bInCapture = false;
         }
    }

    // Set the next think time
    pev->nextthink = gpGlobals->time + 0.1;

}
void CCaptureTeam2 :: Touch( CBaseEntity* pOther )
{
    // Determine if the object that touches it, is a player
    // and check if the player is alive.
    if(!pOther)
        return;
    if(!pOther->IsPlayer())
        return;
    if(!pOther->IsAlive())
        return;

    CBasePlayer *pPlayer = (CBasePlayer *)pOther;

     if(pPlayer && pPlayer->m_iTeam == 2)
     {
          // Check to see if they have the object
          if( !pPlayer->m_fHasObject )
              return;
          else
          {
              // Print to HUD who has captured the flag
              UTIL_ClientPrintAll( HUD_PRINTCENTER, UTIL_VarArgs
              ( "%s has captured the Flag!\n", STRING( pPlayer->pev->netname )));

              // Remove the object
              pPlayer->m_fHasObject = false;

              PLAYBACK_EVENT_FULL(0, pPlayer->edict(), g_usObject, 0, (float *)&g_vecZero,
              (float *)&g_vecZero, 0, 0, FLAG_CAPTURE, 0, 0, 0);

              // Reset the object
              CObjectFlag *pFlag = (CObjectFlag *)UTIL_FindEntityByClassname(NULL, "object_flag");
              if(pFlag)
              {
                   pFlag->m_fIsInPlay = false;

                   // Do a funky effect on the flag when it gets reset
                   pFlag->pev->effects = EF_BRIGHTFIELD;
              }
          }
    }
    else
        return; // Wrong team
}


void CCaptureTeam2 :: KeyValue( KeyValueData* Data )
{
// This will store the points but its not fully implemented. I'll leave it for you to do.
    if( FStrEq( Data->szKeyName, "points" ) )
    {
        int m_iPoints = atoi(Data->szValue);
        Data->fHandled = true;
    }

    CBaseEntity::KeyValue(Data); // call the parent function
}

#3 - Coding Client Side and FGD
Open up hl_events.cpp and find the following:
void EV_TripmineFire( struct event_args_s *args );
and put this after it :

Code:

void EV_Flag( struct event_args_s *args );

Next, in the same file, find:
gEngfuncs.pfnHookEvent( "events/tripfire.sc", EV_TripmineFire );
and after it put this :

Code:

gEngfuncs.pfnHookEvent( "events/object.sc", EV_Flag );

Next, in ev_hldm.cpp, find:
void EV_TripmineFire( struct event_args_s *args );
and at the end of that function put this :

Code:

void EV_Flag(struct event_args_s *args );

Same file, ev_hldm.cpp, find:
void EV_TripmineFire( event_args_t *args )
and at the end of that function put this :

Code:

#define FLAG_STOLEN 1
#define FLAG_CAPTURE    2
#define FLAG_DROPPED    3

void EV_Flag( event_args_t *args )
{
 � �int idx = args->entindex;
 � �int type = args->iparam1;

 � �// Feel free to change the model that is attached to the player
 � �int FlagModel = gEngfuncs.pEventAPI->EV_FindModelIndex("models/flag.mdl");

 � �switch( type )
 � �{
 � �case FLAG_STOLEN:
 � � � � � �// Attach model to player
 � � � � � �gEngfuncs.pEfxAPI->R_AttachTentToPlayer( idx, FlagModel, 52, 9999); // The 52 is the z offset from
 � � � � � �the player and the 9999 is how long you want it to be attached for
 � � � � � �// Add more stuff here if you like
 � � � � � �break;
 � �case FLAG_CAPTURE:
 � � � � � �// Add stuff here if you like
 � �case FLAG_DROPPED:
 � � � � � �// Add more stuff here if you like
 � � � � � �// This gets rid of the attached model
 � � � � � �gEngfuncs.pEfxAPI->R_KillAttachedTents(idx);
 � � � � � �break;
 � �}
}

Code to add at the bottom of your FGD :

Code:

@PointClass = object_flag: "The Flag" []
@SolidClass base(Targetx) = capture_team1: "Where Team 1 brings the Flag"
[
    m_iPoints(integer) : "Points" : 1
]
@SolidClass base(Targetx) = capture_team2: "Where Team 2 brings the Flag"
[
    m_iPoints(integer) : "Points" : 1
]

Tutorial by DarkNight :
#1 - Creating Flag Entity Original Version : http://articles.thewavelength.net/203/
#2 - Creating Capture Point Entity Original Version : http://articles.thewavelength.net/205/
#3 - Coding in Client Side and FGD Original Version : http://articles.thewavelength.net/206/

Enjoy!
